DSB 1/6 BG
Universal drilling rig for subsoil exploration - Powerful, precise, flexible
Our new development sets new standards in subsoil exploration. The universal drill rig with a Düsterlohhammer masters dry and flush drilling methods effortlessly. Driven by a powerful Volvo® Penta D5 engine with 160 kW and equipped with a sturdy frame and proven chain drive, it delivers maximum reliability even under the most demanding conditions. The transport weight is approx. 13,500 kg.
The state-of-the-art control station with 12-inch colour display, N-Drill and joystick control guarantees maximum control and precise work. Intelligent CAN bus control, sensitive hydraulic systems and flexible drilling functions make the machine extremely efficient and versatile.
Made in Germany - customised to your requirements.
Technical specifications
Device Carrier
Crawler undercarriage
Chassis
with solid rubber tracks
Engine Power
160 kW
Emission Standard
EU Stage 5
Tractive Force
60 kN
Feed Length
4,6 m
Drilling Head Torque
10.000 Nm
Rotation Speed
350 U/min
Hollow Shaft / Inner Diameter
75 mm
Machine Width
2.000 mm
Total Weight
12.500 kg
Field of application
Subsoil investigation
Well construction
Sampling
Core drillings
Possible drilling methods
Direct flush drilling
Dry drilling
Auger drilling
Percussion coring (Düsterloh hammer)
Core drilling
Hollow stem auger drilling
Options Equipment features
Cable winch 10,000 kg
rotary casing table Ø 324 mm
eccentric screw pump
Hydraulic clamping head
clamping device
Auxiliary compressor
Compressor
High pressure cleaner
Drilling depth measurement
cable depth measurement
Flow meter measuring device for water
Drill Pipe Break-Out System
Power generator
Device monitoring and fleet management (SMAGLink)
External hydraulic connections
Tractive force
60 kN
Chassis
with solid rubber tracks
